Vibration |
|
Model
|
ABE042
|
| PN No. |
204-042-100-011
|
|
Catalog
|
NIL |
|
Description
|
19′′ 6U System Rack
|
| Origin |
Switzerland
|
| HS CODE |
85389091
|
| Dimension |
12*11*8 (CM)
|
| Weight | 6.5 kg |
Description:
ABE042 204-042-100-011 is a 6U height, 19-inch standard industrial chassis in the Parker Meggitt VM600 series, specifically designed for mechanical protection and condition monitoring applications of rotating mechanical equipment.
204 indicates the category of the VM600 system chassis.
Type 042 is clearly defined as ABE042. The main difference between ABE042 and ABE040 is that the installation bracket is located at the rear of the chassis, which is convenient for installation in control cabinets with limited depth.
100-011 usually represents the basic hardware version. The specific details need to be confirmed in combination with the complete order code.
The 204-042-100-011 chassis itself is a passive backplane platform, designed to accommodate and interconnect various VM600 functional cards (such as processor cards, input/output cards, relay cards, etc.), and to achieve high-speed data communication and power distribution through the integrated VME bus and dedicated signal bus. ABE042 is not an independent working device, but the "skeleton" and "central nervous system" of the entire VM600 monitoring system.
Features:
- Standard rack design
VM600-ABE042 204-042-100-011 adopts a standard 19-inch rack design, which is easy to install and integrate into existing automation systems.
- Highly integrated
The module integrates multiple functions, including vibration monitoring, combustion control, process control, etc., reducing system complexity and maintenance costs.
- High performance
The use of advanced processor technology and large-capacity memory ensures excellent performance in real-time control applications, can quickly process large amounts of data, and meet high-demand automation tasks.
- Modular design
Allows users to flexibly configure the system according to actual needs, and can add or delete input/output modules, communication modules, etc. to adapt to different application requirements.
- Scalability
Supports a variety of expansion options, including additional memory, communication interfaces, etc., to meet more complex application requirements.
- High reliability
Adopts rigorously tested and verified hardware and software to ensure stable operation in various industrial environments.
Parameters:
Product Name: ABE042 204-042-100-011
Maximum switching voltage : ± 30 VRMS / ± 42.4 VAC(PEAK) or 60 VDC
Maximum switching current : 4 AAC , 3 ADC
Operating Temperature: 0 to 70 °C (32 to 158 °F)
Storage Temperature : −40 to 85 °C (−40 to 185 °F)
Humidity : 0 to 90 %, non-condensing
Vibration : 10 to 55 Hz, 0.35 mm peak, 6 hours in each direction
Shock : 15 g peak, 11 ms, half-sine pulse
Datasheet Link:
VM600-ABE042 204-042-100-011 19′′ 6U System Rack PDF Datasheet
